Modal Analysis of a Composite Monocoque Using Ansys Workbench

Current Status
Not Enrolled
Price
Free
Get Started

The monocoque, which is French for "single-shell," is a type of structure in which the object’s outer or external skin carries all the tensile and compressive stresses. These are typically used for boats, aircraft bodies, and, to a limited extent, in automotive chassis. The popularity of monocoque construction is because of its strength and cheaper costs compared to other manufacturing techniques. Carbon-fiber-reinforced composite monocoques are quite common in the racing industry. An engineer designing these monocoques, say for an automobile, has to understand the excessive vibrations in the structural skin of the car as these can degrade or destroy the structural integrity of the vehicle.

For designing any system, it is important to know its natural frequency modes. If the structure experiences vibrations in the range of its natural frequency, it creates resonance and can cause a catastrophic failure. Monocoque designers must be aware of these frequency modes to avoid the resonance.

This SimCafe Course was developed by Dr. Rajesh Bhaskaran, Swanson Director of Engineering Simulation at Cornell University, and Jingsi Wu, in partnership with Ansys. It was last modified by Sebastien Lachance-Barrett. It serves as an e-learning resource to integrate industry-standard simulation tools into courses and provides a resource for supplementary learning outside the classroom. In this course we show the modal analysis of a monocoque component.

For more ways to learn, check out the Cornell edX course, A Hands-on Introduction to Engineering Simulations at ansys.com/cornell.

Cornell University also offers a Fluid Dynamics Simulations Using Ansys online certificate authored by Dr. Rajesh Bhaskaran. Learn more here: https://ecornell.cornell.edu/fluiddynamics.

Recommended Courses

Buckling analysis calculates the buckling load factor and associated mode shapes. The buckling load factor multiplied by the applied load gives the magnitude of the compressive load that can cause buckling. In this SimCafe course, you will learn to analyze buckling on a simple column by following the end-to-end workflow in Ansys Structural. You will create the computational mesh and set up the boundary conditions needed for the simulation. The fundamental concepts and the steps needed to successfully model this structural problem are explained using immersive step-by-step walk-through videos.

When designing any system, it is important to have a sound knowledge of its naturally excited vibration frequency. If the structure experiences an external vibration in the range of its natural frequency, it creates resonance. This can cause a catastrophic failure of the system. In this SimCafe course, you will learn the end-to-end workflow for importing a realistic geometry and understand the importance of performing modal analysis of a space satellite. You will set up the boundary conditions needed for the simulation. The fundamental concepts and the steps needed to successfully model this structural problem are explained using step-by-step instructions.

A body at any temperature can exchange energy with its surroundings in the form of thermal radiation, which is characterized by the emission of electromagnetic waves from the body. It is the only mode of heat transfer that does not require a medium and can take place in a vacuum. Therefore, in space applications, it becomes important to understand the amount of heat incident on the systems. In this Simcafe Course we show how to analyze and estimate the net thermal radiation of a system under realistic boundary conditions using Ansys Transient Thermal.
